Shenzhen C-Data Technology Co., Ltd.
Shenzhen C-Data Technology Co., Ltd.
Overview Specs Ordering Information
FD512XW-R470 - 翻译中... FD504XW-X-R416 - 翻译中... FD712XW-R460 - 翻译中... FD812XW-R460 - 翻译中... FD612XW-R470 - 翻译中...
Dual-band WiFi Optional, High-Speed Connection - 翻译中...

Dual-band WiFi Optional, High-Speed Connection - 翻译中...

翻译中...

Serve Multiple Services - 翻译中...

  • voice onu for internet
  • voice onu for wifi
  • voice onu for voip

Technical Overview

  • optical network unit router
  • ont onu
  • optical network unit router
  • ont onu
翻译中...
Datasheet Get Docs

Technical Specifications

Item
FD612XW-R460
Specifications
1*xPON + 1*FE RJ45 + 1*GE RJ45 + 1*POTS + Wi-Fi
GPON/EPON Port
Single mode single fiber
GPONFSAN G.984.2 standard,Class B+
EPON1000BASE-PX20+ symmetric
GPON2.488Gbps/1.244Gbpsdownstream/upstream
EPON1.25Gbps downstream/upstream
WavelengthTransmit: 1310nm Receiver: 1490nm
Receiving sensitivityGPON：-28dBm EPON：-27dBm
Saturated powerGPON：-8dBm EPON：-3dBm
Transmitting powerGPON：0.5～5dBm EPON:0～4dBm
User Port(LAN)
RJ-45 connector

1*10/100 and1 *10/100/1000Mbps adaptive Ethernet port

Full/half duplex

Auto MDI/MDI-X
User Port(POTS)
RJ-11 connector

1*POTS

SIP protocol

TDMF

G711U/G711A/G729/G722 encoding and decoding
WIFI performance parameters
IEEE802.11b/g/n(2.4G)

Max rate: 300M(2.4G)

MAX TX power 2.4G:17dBm
Indicators
PWR / PON / LOS / GE / FE / TEL / WIFI / INT / OPT
Power
External 12VDC/1A power supply adapter

Power consumption:<9W
Dimension and WeightItem Dimension214*139.5*32mm
Item weight300g
Environmental SpecificationsOperating temperature0 to 40ºC
Storage temperature-40 to 85ºC
Operating humidity10% to 90%(Non-condensing)



Technical Specifications

Item

  • FD612XW-R460

Specifications

  • 1*xPON + 1*FE RJ45 + 1*GE RJ45 + 1*POTS + Wi-Fi

GPON/EPON Port

  • Single mode single fiber

GPON

  • FSAN G.984.2 standard,Class B+

EPON

  • 1000BASE-PX20+ symmetric

GPON

  • 2.488Gbps/1.244Gbpsdownstream/upstream

EPON

  • 1.25Gbps downstream/upstream

Wavelength

  • Transmit: 1310nm Receiver: 1490nm

Receiving sensitivity

  • GPON：-28dBm

  • EPON：-27dBm

Saturated power

  • GPON：-8dBm

  • EPON：-3dBm

Transmitting power

  • GPON：0.5～5dBm

  • EPON:0～4dBm

User Port(LAN)

  • RJ-45 connector

  • 1*10/100 and1 *10/100/1000Mbps adaptive Ethernet port

  • Full/half duplex

  • Auto MDI/MDI-X

User Port(POTS)

  • RJ-11 connector

  • 1*POTS

  • SIP protocol

  • TDMF

  • G711U/G711A/G729/G722 encoding and decoding

WIFI performance parameters

  • IEEE802.11b/g/n(2.4G)

  • Max rate: 300M(2.4G)

  • MAX TX power 2.4G:17dBm

Indicators

  • PWR / PON / LOS / GE / FE / TEL / WIFI / INT / OPT

Power

  • External 12VDC/1A power supply adapter

  • Power consumption:<9W

Dimension and Weight
Item Dimension

  • 214*139.5*32mm

Item weight

  • 300g

Environmental Specifications
Operating temperature

  • 0 to 40ºC

Storage temperature

  • -40 to 85ºC

Operating humidity

  • 10% to 90%(Non-condensing)


Ordering Information

NO.Product ModelSpecificationsAccessories
1FD612XW-R4601*xPON + 1*FE RJ45 + 1*GE RJ45 + 1*POTS + Wi-FiAC-DC Power Adapter: DC 12V/0.5A
2FD612GD-R4601*xPON + 2*GE RJ45 + 1*POTS + Dual-Band Wi-FiAC-DC Power Adapter: DC 12V/0.5A
3FD604GW-DX1*xPON + 4*GE RJ45 + 2*POTS + Wi-FiAC-DC Power Adapter: DC 12V/0.5A



Ordering Information

NO.

  • 1

  • 2

  • 3

Product Model

  • FD612XW-R460

  • FD612GD-R460

  • FD604GW-DX

Specifications

  • 1*xPON + 1*FE RJ45 + 1*GE RJ45 + 1*POTS + Wi-Fi

  • 1*xPON + 2*GE RJ45 + 1*POTS + Dual-Band Wi-Fi

  • 1*xPON + 4*GE RJ45 + 2*POTS + Wi-Fi

Accessories

  • AC-DC Power Adapter: DC 12V/0.5A

  • AC-DC Power Adapter: DC 12V/0.5A

  • AC-DC Power Adapter: DC 12V/0.5A
