Shenzhen C-Data Technology Co., Ltd.
Shenzhen C-Data Technology Co., Ltd.
Overview Specs Ordering Information
FD514GD-R470 - 翻译中... FD512GD-R470 - 翻译中... FD604GW-DX-R710 - 翻译中... FD612GD-R460 - 翻译中... FD712GD-R460 - 翻译中... FD814GD-R770 - 翻译中... FD714GW-R760 - 翻译中... FD714GD-R880 - 翻译中...
Multiple Ports Available - 翻译中...

Multiple Ports Available - 翻译中...

翻译中...
WiFi Optional, High-Speed Connection - 翻译中...

WiFi Optional, High-Speed Connection - 翻译中...

翻译中...
Network Management? So easy! - 翻译中...

Network Management? So easy! - 翻译中...

翻译中...
Innovative Products, Awarded 2+ Patents - 翻译中...

Innovative Products, Awarded 2+ Patents - 翻译中...

翻译中...

Application Scenarios - 翻译中...

  • catv onu for internet
  • catv onu for catv
  • catv onu for wifi

Technical Overview

  • fd714gd r880 1
  • fd714gd r880 2
  • fd714gd r880 3
  • fd714gd r880 1
  • fd714gd r880 2
  • fd714gd r880 3
翻译中...
Datasheet Get Docs

Technical Specifications

Mechanics

Dimensions

210mm*135mm*45mm

Weight

About 300g


Hardware

User Port (LAN)

RJ-45 connector

4 *10/100/1000Mbps adaptive Ethernet port

Full/half duplex

Auto MDI/MDI-X

Indicators

PWR / PON / LOS / LAN / INT / CATV /WIFI

PON Port

PON Mode

EPON：1000BASE-PX20+ symmetric

GPON：FSAN G.984.2 standard,Class B+

PON Rate

EPON：1.25Gbps downstream/upstream

GPON：2.488Gbps/1.244Gbps downstream/upstream

Wavelength

Transmit: 1310nm

Receiver: 1490nm

Receiving sensitivity

EPON：-27dBm   GPON：-28dBm

Saturated power

EPON：-3dBm    GPON：-8dBm

Transmitting power

EPON:0～4dBm   GPON：0.5～5dBm


CATV（Input /Output port）


Wavelength: 1550nm

Input optical power: -18dBm～0dBm(with AGC)

RF frequency: 47MHz~1000MHz

RF output level: 78dBuV (@-12~-2dBm@85MHz) (with AGC)

RF output return loss: >12dB(with AGC)

RF impedance: 75Ω


WIFI performance parameters

IEEE802.11b/g/n(2.4G)

IEEE802.11a/n/ac(5G)

Max rate: 300M(2.4G)

Max rate: 867Mbps(5G)

MAX TX power:17dBm(2.4G)

MAX TX power:17dBm(5G)


Environment

Working temperature

0 to 40ºC

Operating humidity

10% ~ 90% (Non-condensing)


Environment

Working temperature

0 to 40ºC

Operating humidity

10% ~ 90% (Non-condensing)


Technical Specifications

Mechanics

Dimensions

  • 210mm*135mm*45mm

Weight

  • About 300g



Hardware

User Port (LAN)

  • RJ-45 connector

  • 4 *10/100/1000Mbps adaptive Ethernet port

  • Full/half duplex

  • Auto MDI/MDI-X

Indicators

  • PWR / PON / LOS / LAN / INT / CATV /WIFI

PON Port

PON Mode

  • EPON: 1000BASE-PX20+ symmetric

  • GPON: FSAN G.984.2 standard, Class B+

PON Rate

  • EPON：1.25Gbps downstream/upstream

  • GPON：2.488Gbps/1.244Gbps downstream/upstream

Wavelength

  • Transmit: 1310nm

  • Receiver: 1490nm

Receiving sensitivity

  • EPON：-27dBm

  • GPON：-28dBm

Saturated power

  • EPON：-3dBm

  • GPON：-8dBm

Transmitting power

  • EPON:0～4dBm

  • GPON：0.5～5dBm



CATV（Input /Output port）

Wavelength

  • 1550nm

Input optical power

  • -18dBm～0dBm(with AGC)

RF frequency

  • 47MHz~1000MHz

RF output level

  • 78dBuV (@-12~-2dBm@85MHz) (with AGC)

RF output return loss

  • >12dB(with AGC)

RF impedance

  • 75Ω



WIFI performance parameters

IEEE802.11b/g/n(2.4G)

IEEE802.11a/n/ac(5G)

Max rate: 300M(2.4G)

Max rate: 867Mbps(5G)

MAX TX power:17dBm(2.4G)

MAX TX power:17dBm(5G)



Environment

Working temperature

  • 0 to 40ºC

Operating humidity

  • 10% ~ 90% (Non-condensing)



Environment

Working temperature

  • 0 to 40ºC

Operating humidity

  • 10% ~ 90% (Non-condensing)


Ordering Information

NO.Product ModelSpecificationsAccessories
1FD711G-F3601*xPON + 1*GE RJ45 + 1*RF CATVAC-DC Power Adapter: DC 12V/0.5A
2FD712XW-R4601*xPON + 2*GE RJ45 + 1*RF CATV + Wi-FiAC-DC Power Adapter: DC 12V/0.5A
3FD712GD-R4601*xPON + 2*GE RJ45 + 1*RF CATV + Dual-Band Wi-FiAC-DC Power Adapter: DC 12V/0.5A
4FD704G-X-R4101*xPON + 4*GE RJ45 + 1*RF CATVAC-DC Power Adapter: DC 12V/0.5A
5FD714GD-R8801*xPON + 4*GE RJ45 + 1*RF CATV + Dual-Band Wi-FiAC-DC Power Adapter: DC 12V/0.5A


Ordering Information

NO.

  • 1

  • 2

  • 3

  • 4

  • 5

Product Model

  • FD711G-F360

  • FD712XW-R460

  • FD712GD-R460

  • FD704G-X-R410

  • FD714GD-R880

Specifications

  • 1*xPON + 1*GE RJ45 + 1*RF CATV

  • 1*xPON + 2*GE RJ45 + 1*RF CATV + Wi-Fi

  • 1*xPON + 2*GE RJ45 + 1*RF CATV + Dual-Band Wi-Fi

  • 1*xPON + 4*GE RJ45 + 1*RF CATV

  • 1*xPON + 4*GE RJ45 + 1*RF CATV + Dual-Band Wi-Fi

Accessories

  • AC-DC Power Adapter: DC 12V/0.5A

  • AC-DC Power Adapter: DC 12V/0.5A

  • AC-DC Power Adapter: DC 12V/0.5A

  • AC-DC Power Adapter: DC 12V/0.5A

  • AC-DC Power Adapter: DC 12V/0.5A
